EMC Industries
1- EMC Steel Fabrication Company:- Located in Saudi Arabia at total operating area 50,000 SQM with annual capacities as below
- 20K Ton for steel structure.
- 12K Ton for plate work.
- 8K Ton lighting poles and masts.
- 8K Ton Transmissions and telecommunication Towers.
2- EMDAD Steel:- Located in 10th of Ramada at total operating area 80,000 SQM with annual capacities as below
- 24K Ton for steel structure.
- 18K Ton for plate work.
- 10K Ton lighting poles and masts.
- 12K Ton Transmissions and telecommunication Towers.
3- EMDAD Galvanization Products:- Located in 10th of Ramadan at total operation area 50,000 SQM with annual capacity 60K Ton
4- HF Tube:- Located in Alexandria Borg El-arab at total operating area 7000 SQM with annual capacity 6K Ton
Shot Blasting Machine
- SAT-3100/1500TN16 Roller Conveyor Type Shot Blasting Machine
- Model : - SAT-3100/1500TN16.
Beam Processing Line
- CNC Drill Beam Line With Automatic Band SAW.
- Model: - 3ADM 1200 CNC DRILLING-Marking & SAWING LINE.
CNC Shearing Machine
- Model: - HNC 6113 CNC SHEAR .
- Max. Length: - 6000mm.
- Max. Cutting Thick: - 13mm.
Angle Master
- CNC Angle Punching Marking Shearing.
- Model: - APL2020A.
- Angle Size: - L40x 440 * 9 -- L200 * 200 * 20.
- Max. Punching Capability: - 23*20 (mm).
CNC Pending Machine
- Model: - APHS61440 CNC PRESS BRAI .
- Max. Length: - 6000mm.
- Max. Bending Thick: - 14mm.
H Beam Welding Line
table { border-collapse: collapse; width: 100%; } th, td { text-align: left; padding: 7px; } tr:nth-child(even) {background-color: #f2f2f2;}
| # | Description | Specification ABW 1500 |
|---|---|---|
| 1 | WEB width - Minimum | 225 mm/ 175mm web with the option of LASER SEAM TRACKER |
| 2 | WEB width - Maximum | 1450 mm |
| 3 | WEB thickness - Minimum | 4 mm |
| 4 | WEB thickness - Maximum | 16 mm |
| 5 | FLANGE height - Minimum | 220 mm |
| 6 | FLANGE height - Maximum | 600 mm |
| 7 | FLANGE thickness - Minimum | 5 mm |
| 8 | Minimum FLANGE thickness | 25 mm |
| 9 | Maximum Web Taper Angle | 15° (in Degrees) |
| 10 | Maximum Beam Width overall | 1500mm |
| 11 | Maximum Beam Length - Minimum / Maximum | 2.5 M to 18.0 M |
CNC plasma & Oxyfuel cutting
table { border-collapse: collapse; width: 100%; } th, td { text-align: left; padding: 7px; } tr:nth-child(even) {background-color: #f2f2f2;}
| Item | Type | QTY |
|---|---|---|
| Plasma Power Source | Fineline300HD | 1 |
| OxyFuel torch | HArris (LE) 98-2TF | 6 |
| Gantry | ACECUT 5mx17m | 1 |
| Rails | 17m (Travel Distance 14m) | 1 |
| CNC Controller | HPC Controller | 1 |
| Nesting Software | Lantek | 1 |
CNC high speed drilling
table { border-collapse: collapse; width: 100%; } th, td { text-align: left; padding: 7px; } tr:nth-child(even) {background-color: #f2f2f2;}
| Model | PHD3016 | |
|---|---|---|
| Max.Size of workpiece Length(mm) | Max.Size of workpiece Length * Width (mm) | 3000x1600 |
| Max. thickness (mm) | 150 | |
| Drilling spindle | Quantity | 1 |
| Spindle taper | BT50 | |
| Range of drilling diameter (mm) | $12-$60 | |
| Range of Tapping | M6-M24 | |
| Rotation speed(conver, stepless) (r/min) | 30-3000 | |
| Motor power of spindles(kW) | 18.5(232Nm) | |
| Spindle nether surface to work table(mm) | 200~700 | |
| Longitudinal movement of gantry (X axis) | Max. stroke (mm) | 3000 |
| X axis feeding speed (m/min) | 0-8 | |
| X axis servo motor power (kW) | 2.3x2 | |
| Horizontal move (Y axis) | Max. Stroke (mm) | 1600 |
| X axis feeding speed (m/min) | 0-8 | |
| X axis servo motor power (kW) | 2.3 | |
| Vertical move (Z axis) | Max. Stroke (mm) | 500 |
| Y axis feeding speed (m/min) | 0-5 | |
Iron worker
- EMDAD Scope: - Supply, Fabrication and Delivery of complete bag filter and the relative steel structure works.
- Location: - Ireland.
